Raspberry Pi aluminium case.
Suitable for Raspberry Pi 2B, 3B and 3B+ boards.
Superior heat dissipation all aluminium case with elegant metallic silver coating finish.
The internal part is made to be conductive.

3 types are available : normal, double-layered, and flanged.

*Raspberry Pi Board is not included.
3D View - Single type  3D View - Double type  3D View - Wall mount type 

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Type Weight (g) PDF DXF DWG STP
W H D
RPI-1 65 37 95 Single board type 90.5 PDF DXF DWG
RPI-2 65 65 95 Double layered type 136.0 PDF DXF DWG
RPI-1F 65 37 95 With wall mount flange (VESA mount) 91.5 PDF DXF DWG
