RUBBER STRAIN RELIEF CORD PROTECTOR CBS series


CBS Series -PDF

CATEGORY：Cable bussing, Cable bush, Cable strain relief, Cord stopper, Cord protector

RUBBER STRAIN RELIEF CORD PROTECTOR CBS series
RUBBER STRAIN RELIEF CORD PROTECTOR CBS series
RUBBER STRAIN RELIEF CORD PROTECTOR CBS series
RUBBER STRAIN RELIEF CORD PROTECTOR CBS series1
RUBBER STRAIN RELIEF CORD PROTECTOR CBS series2
RUBBER STRAIN RELIEF CORD PROTECTOR CBS series3
Strain relief cord protector help relief flex stress and damage to cables.
2 types - round and flat - are available.
Insert from the inner side of the case / panel of the enclosure.
Made from high heat resistant silicone material.
Color: Black(Similar to Munsell N1) / Off white(Similar to Munsell N8.75)

※ Does not prevent cables from being dislodged.

PRODUCT NO. / DIMENSIONS

Product No. Cable shape Applicable cable diameter / type Installation hole diameter (mm) Mounting thickness (mm) Color / Similar matching Weight (g) / 1pcs Pack of PDF DXF DWG
CBS3055-15B Flat type VFF0.75×2 7.6～7.8 1.5～2.0 Black / Munsell N1 0.6 10 PDF DXF DWG
CBS3055-15W Flat type VFF0.75×2 7.6～7.8 1.5～2.0 Off-white / Munsell N8.75 0.6 10 PDF DXF DWG
CBS3055-20B Flat type VFF0.75×2 7.6 - 7.8 2.0 - 2.5 Black / Munsell N1 0.6 10 PDF DXF DWG
CBS3055-20W Flat type VFF0.75×2 7.6 - 7.8 2.0 - 2.5 Off-white / Munsell N8.75 0.6 10 PDF DXF DWG
CBS35-15B Round type φ3.5 5.6～5.8 1.5～2.0 Black / Munsell N1 0.4 10 PDF DXF DWG
CBS35-15W Round type φ3.5 5.6～5.8 1.5～2.0 Off-white / Munsell N8.75 0.4 10 PDF DXF DWG
CBS35-20B Round type φ3.5 5.6 - 5.8 2.0 - 2.5 Black / Munsell N1 0.4 10 PDF DXF DWG
CBS35-20W Round type φ3.5 5.6 - 5.8 2.0 - 2.5 Off-white / Munsell N8.75 0.4 10 PDF DXF DWG
CBS45-15B Round type φ4.5 6.6～6.8 1.5～2.0 Black / Munsell N1 0.5 10 PDF DXF DWG
CBS45-15W Round type φ4.5 6.6～6.8 1.5～2.0 Off-white / Munsell N8.75 0.5 10 PDF DXF DWG
CBS45-20B Round type φ4.5 6.6 - 6.8 2.0 - 2.5 Black / Munsell N1 0.5 10 PDF DXF DWG
CBS45-20W Round type φ4.5 6.6 - 6.8 2.0 - 2.5 Off-white / Munsell N8.75 0.5 10 PDF DXF DWG
CBS60-15B Round type φ6.0 8.1～8.3 1.5～2.0 Black / Munsell N1 0.7 10 PDF DXF DWG
CBS60-15W Round type φ6.0 8.1～8.3 1.5～2.0 Off-white / Munsell N8.75 0.7 10 PDF DXF DWG
CBS60-20B Round type φ6.0 8.1 - 8.3 2.0 - 2.5 Black / Munsell N1 0.7 10 PDF DXF DWG
CBS60-20W Round type φ6.0 8.1 - 8.3 2.0 - 2.5 Off-white / Munsell N8.75 0.7 10 PDF DXF DWG
