PROTECTOR CASE with KEY LOCK - NKK series

PROTECTOR CASE with KEY LOCK - NKK series

CATEGORY：Waterproof & Dustproof case, Carrying case, Protection case, Protective hard case, Protector case, Shockproof case, Rugged case, Military case, Flight case

PROTECTOR CASE with KEY LOCK - NKK series1

PROTECTOR CASE with KEY LOCK - NKK series2

PROTECTOR CASE with KEY LOCK - NKK series3

PROTECTOR CASE with KEY LOCK - NKK series4

PROTECTOR CASE with KEY LOCK - NKK series5

PROTECTOR CASE with KEY LOCK - NKK series6

PROTECTOR CASE with KEY LOCK - NKK series7

PROTECTOR CASE with KEY LOCK - NKK series8

PROTECTOR CASE with KEY LOCK - NKK series9

PROTECTOR CASE with KEY LOCK - NKK series10

Durable and stylishly designed waterproof protector lockable case.
Equipped with a TSA lock latch for security, or transportation as check-in baggage.

Optional aluminium panel can turn the NKK series into your own original controller, measuring device, or portable power supply.

Protection class : IP65
Selectable in 18 different sizes.
For 17 sizes, with and without foam types are available.
Color code：Black(Similar to PANTONE Black 3C)

NKK - DETAILS AND FUNCTIONS CUSTOMIZATION

PRODUCT NO. / DIMENSIONS

Product No.	External dimensions			Internal dimensions			Form insert	Equipment	Color	Weight (Kg)	PDF	DXF	DWG
Product No.	W	H	D	w	h	d	Form insert	Equipment	Color	Weight (Kg)	PDF	DXF	DWG
NKK905B	316	257	152	209	146	129	Without	-	Black	1.6	PDF	DXF	DWG
NKK908B	318	249	203	203	134	180	Without		Black	1.5	PDF	DXF	DWG
NKK915B	391	309	172	305	179	146	Without	-	Black	2.1	PDF	DXF	DWG
NKK918B	425	326	232	332	178	207	Without	-	Black	2.9	PDF	DXF	DWG
NKK920B	424	342	172	338	211	146	Without	-	Black	2.4	PDF	DXF	DWG
NKK923B	471	364	161	383	222	123	Without		Black	2.7	PDF	DXF	DWG
NKK925B	474	373	178	387	242	151	Without	-	Black	2.9	PDF	DXF	DWG
NKK930B	500	405	191	412	274	164	Without	-	Black	3.4	PDF	DXF	DWG
NKK933B	503	408	255	408	258	226	Without	-	Black	3.9	PDF	DXF	DWG
NKK935B	560	355	229	416	231	179	Without	Retractable handle・Wheels	Black	5.3	PDF	DXF	DWG
NKK938B	605	395	336	440	239	283	Without	Retractable handle・Wheels	Black	6.4	PDF	DXF	DWG
NKK940B	551	430	216	460	296	189	Without	-	Black	3.9	PDF	DXF	DWG
NKK945B	648	508	222	511	359	195	Without	-	Black	5	PDF	DXF	DWG
NKK950B	581	464	298	416	316	247	Without	Retractable handle・Wheels	Black	7	PDF	DXF	DWG
NKK960B	646	509	368	466	356	316	Without	Retractable handle・Wheels	Black	9	PDF	DXF	DWG
NKK963B	825	536	317	627	373	257	Without	Retractable handle・Wheels	Black	10.2	PDF	DXF	DWG
NKK980B	760	409	186	635	276	142	Without	Wheels	Black	4.9	PDF	DXF	DWG
NKK990B	1196	439	168	1061	303	143	Without		Black	8.3	PDF	DXF	DWG
NKK905BS	316	257	152	209	146	129	With foam	-	Black	1.7	PDF	DXF	DWG
NKK908BS	318	249	203	203	134	180	With foam		Black	1.7	PDF	DXF	DWG
NKK915BS	391	309	172	305	179	146	With foam	-	Black	2.4	PDF	DXF	DWG
NKK918BS	425	326	232	332	178	207	With foam	-	Black	2.9	PDF	DXF	DWG
NKK920BS	424	342	172	338	211	146	With foam	-	Black	2.7	PDF	DXF	DWG
NKK923BS	471	364	161	383	222	123	With foam		Black	3.1	PDF	DXF	DWG
NKK925BS	474	373	178	387	242	151	With foam	-	Black	3.3	PDF	DXF	DWG
NKK930BS	500	405	191	412	274	164	With foam	-	Black	3.9	PDF	DXF	DWG
NKK933BS	503	408	255	408	258	226	With foam	-	Black	4.6	PDF	DXF	DWG
NKK935BS	560	355	229	416	231	179	With foam	Retractable handle・Wheels	Black	6	PDF	DXF	DWG
NKK938BS	605	395	336	440	239	283	With foam	Retractable handle・Wheels	Black	7.1	PDF	DXF	DWG
NKK940BS	551	430	216	460	296	189	With foam	-	Black	4.6	PDF	DXF	DWG
NKK945BS	648	508	222	511	359	195	With foam	-	Black	6	PDF	DXF	DWG
NKK950BS	581	464	298	416	316	247	With foam	Retractable handle・Wheels	Black	8	PDF	DXF	DWG
NKK960BS	646	509	368	466	356	316	With foam	Retractable handle・Wheels	Black	10.5	PDF	DXF	DWG
NKK980BS	760	409	186	635	276	142	With foam		Black	5.5	PDF	DXF	DWG
NKK990BS	1196	439	168	1061	303	143	With foam	Wheels	Black	9.8	PDF	DXF	DWG

Aluminium panel (Option)	PDF	DXF	DWG
Aluminium panel (Option)	PDF	DXF	DWG
NKAP905	PDF	DXF	DWG
NKAP908	PDF	DXF	DWG
NKAP915	PDF	DXF	DWG
NKAP918	PDF	DXF	DWG
NKAP920	PDF	DXF	DWG
NKAP923	PDF	DXF	DWG
NKAP925	PDF	DXF	DWG
NKAP930	PDF	DXF	DWG
NKAP933	PDF	DXF	DWG
NKAP935	PDF	DXF	DWG
NKAP938	PDF	DXF	DWG
NKAP940	PDF	DXF	DWG
NKAP945	PDF	DXF	DWG
NKAP950	PDF	DXF	DWG
NKAP960	PDF	DXF	DWG
NKAP963	PDF	DXF	DWG


NKAP905	PDF	DXF	DWG
NKAP908	PDF	DXF	DWG
NKAP915	PDF	DXF	DWG
NKAP918	PDF	DXF	DWG
NKAP920	PDF	DXF	DWG
NKAP923	PDF	DXF	DWG
NKAP925	PDF	DXF	DWG
NKAP930	PDF	DXF	DWG
NKAP933	PDF	DXF	DWG
NKAP935	PDF	DXF	DWG
NKAP938	PDF	DXF	DWG
NKAP940	PDF	DXF	DWG
NKAP945	PDF	DXF	DWG
NKAP950	PDF	DXF	DWG
NKAP960	PDF	DXF	DWG
