Extruded aluminum enclosure with heat-sink sides.
Silver anodized end panels makes for a luxurious finish.
Conductivity is achieved by utilizing the contact between the unfinished end panels side, and the unfinished ends of the frame.
PCB or mounting plate can be horizontally mounted by sliding into an inner-grooved body frame.
Suitable for industrial fanless PC, measuring instrument, digital audio amplifier and so on.

Available in 34 sizes.


Custom length is available.
↓Go AWAS series page for the custom length (depth) order from 50～700mm by 1mm intervals.
CUSTOM LENGTH ENCLOSURE - AWAS series  3D View - Small size  3D View - Large size  Exploded view 

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Weight (g) PDF DXF DWG STP
W H D w h d
AWA5-3-5SS 52 32 53.2 36 16.4 49.2 69.5 PDF DXF DWG
AWA5-3-7SS 52 32 73.2 36 16.4 69.2 90.5 PDF DXF DWG
AWA5-3-10SS 52 32 98.2 36 16.4 94.2 116.5 PDF DXF DWG
AWA5-3-12SS 52 32 123.2 36 16.4 119.2 142.5 PDF DXF DWG
AWA6-6-7SS 61 61 68 43 46 64 156 PDF DXF DWG
AWA6-6-10SS 61 61 98 43 46 94 212 PDF DXF DWG
AWA6-6-14SS 61 61 138 43 46 134 286 PDF DXF DWG
AWA6-6-19SS 61 61 188 43 46 184 379 PDF DXF DWG
AWA6-6-24SS 61 61 238 43 46 234 471.5 PDF DXF DWG
AWA8-4-8SS 76 41 78 58 26 74 154 PDF DXF DWG
AWA8-4-10SS 76 41 103 58 26 99 195 PDF DXF DWG
AWA8-4-13SS 76 41 128 58 26 124 236.5 PDF DXF DWG
AWA8-4-16SS 76 41 163 58 26 159 294 PDF DXF DWG
AWA8-8-9SS 82 82 86 62.5 61.5 81 319.5 PDF DXF DWG
AWA8-8-11SS 82 82 111 62.5 61.5 106 392.5 PDF DXF DWG
AWA8-8-16SS 82 82 156 62.5 61.5 151 523.5 PDF DXF DWG
AWA8-8-21SS 82 82 206 62.5 61.5 201 669.5 PDF DXF DWG
AWA8-8-26SS 82 82 261 62.5 61.5 256 829.5 PDF DXF DWG
AWA10-5-10SS 102 52 95.6 82.5 31.5 90.6 288.5 PDF DXF DWG
AWA10-5-14SS 102 52 135.6 82.5 31.5 130.6 387.5 PDF DXF DWG
AWA10-5-18SS 102 52 175.6 82.5 31.5 170.6 486 PDF DXF DWG
AWA10-5-23SS 102 52 225.6 82.5 31.5 220.6 609 PDF DXF DWG
AWA12-7-9SS 115.7 67 90.6 96.7 46 85.6 354 PDF DXF DWG
AWA12-7-12SS 115.7 67 125.6 96.7 46 120.6 460 PDF DXF DWG
AWA12-7-17SS 115.7 67 165.1 96.7 46 160.1 579.5 PDF DXF DWG
AWA12-7-20SS 115.7 67 200.6 96.7 46 195.6 687 PDF DXF DWG
AWA15-8-12SS 152 77 120.6 133 56 115.6 565.5 PDF DXF DWG
AWA15-8-16SS 152 77 160.6 133 56 155.6 712 PDF DXF DWG
AWA15-8-21SS 152 77 210.6 133 56 205.6 895.5 PDF DXF DWG
AWA15-8-26SS 152 77 260.6 133 56 255.6 1079 PDF DXF DWG
AWA20-8-15SS 202.4 77.4 153.8 183 53.5 147.8 854.5 PDF DXF DWG
AWA20-8-19SS 202.4 77.4 193.8 183 53.5 187.8 1025 PDF DXF DWG
AWA20-8-24SS 202.4 77.4 243.8 183 53.5 237.8 1238 PDF DXF DWG
AWA20-8-29SS 202.4 77.4 293.8 183 53.5 287.8 1451.5 PDF DXF DWG
Mounting plate (Option) PDF DXF DWG
AWC5-7 PDF DXF DWG
AWC5-9 PDF DXF DWG
AWC5-11 PDF DXF DWG
AWC5-14 PDF DXF DWG
AWC7-8 PDF DXF DWG
AWC7-11 PDF DXF DWG
AWC7-15 PDF DXF DWG
AWC7-20 PDF DXF DWG
AWC7-25 PDF DXF DWG
AWC8-9 PDF DXF DWG
AWC8-12 PDF DXF DWG
AWC8-14 PDF DXF DWG
AWC8-18 PDF DXF DWG
AWC9-10 PDF DXF DWG
AWC9-13 PDF DXF DWG
AWC9-17 PDF DXF DWG
AWC9-22 PDF DXF DWG
AWC9-28 PDF DXF DWG
AWC11-11 PDF DXF DWG
AWC11-15 PDF DXF DWG
AWC11-19 PDF DXF DWG
AWC11-24 PDF DXF DWG
AWC12-11 PDF DXF DWG
AWC12-14 PDF DXF DWG
AWC12-17 PDF DXF DWG
AWC12-22 PDF DXF DWG
AWC16-14 PDF DXF DWG
AWC16-18 PDF DXF DWG
AWC16-23 PDF DXF DWG
AWC16-28 PDF DXF DWG
AWC21-17 PDF DXF DWG
AWC21-21 PDF DXF DWG
AWC21-26 PDF DXF DWG
AWC21-31 PDF DXF DWG
