CATEGORY:IP65 Enclosure, Water proof aluminium enclosure, Extruded aluminum enclosure, Aluminium profile enclosure, Controller box
COLOR TYPE
PRODUCT NO. / DIMENSIONS
Product No. | External dimensions | Internal dimensions | DXF | DWG | |||||
---|---|---|---|---|---|---|---|---|---|
W | H | D | w | h | d | ||||
EXWS69-34-〇 □ | 69 | 34 | Can be specified from 40 to 500mm by 1mm intervals | 47 | 20 | D dimension-12mm | DXF | DWG | |
EXWS69-44-〇 □ | 69 | 44 | Can be specified from 40 to 500mm by 1mm intervals | 47 | 30 | D dimension-12mm | DXF | DWG | |
EXWS69-59-〇 □ | 69 | 59 | Can be specified from 40 to 500mm by 1mm intervals | 47 | 45 | D dimension-12mm | DXF | DWG | |
EXWS89-39-〇 □ | 89 | 39 | Can be specified from 40 to 500mm by 1mm intervals | 67 | 25 | D dimension-13mm | DXF | DWG | |
EXWS89-49-〇 □ | 89 | 49 | Can be specified from 40 to 500mm by 1mm intervals | 67 | 35 | D dimension-13mm | DXF | DWG | |
EXWS89-64-〇 □ | 89 | 64 | Can be specified from 40 to 500mm by 1mm intervals | 67 | 50 | D dimension-13mm | DXF | DWG | |
EXWS116-41-〇 □ | 116 | 41 | Can be specified from 40 to 500mm by 1mm intervals | 89 | 24 | D dimension-14mm | DXF | DWG | |
EXWS116-56-〇 □ | 116 | 56 | Can be specified from 40 to 500mm by 1mm intervals | 89 | 39 | D dimension-14mm | DXF | DWG | |
EXWS116-71-〇 □ | 116 | 71 | Can be specified from 40 to 500mm by 1mm intervals | 89 | 54 | D dimension-14mm | DXF | DWG | |
EXWS151-46-〇 □ | 116 | 46 | Can be specified from 40 to 500mm by 1mm intervals | 107 | 29 | D dimension-14mm | DXF | DWG | |
EXWS151-61-〇 □ | 151 | 61 | Can be specified from 40 to 500mm by 1mm intervals | 107 | 44 | D dimension-14mm | DXF | DWG | |
EXWS151-81-〇 □ | 151 | 81 | Can be specified from 40 to 500mm by 1mm intervals | 107 | 64 | D dimension-14mm | DXF | DWG | |
EXWS151-101-〇 □ | 151 | 101 | Can be specified from 40 to 500mm by 1mm intervals | 107 | 84 | D dimension-14mm | DXF | DWG |
