Simple, low-cost universal aluminum sheet metal enclosure.
The inner surface is unfinished, allowing the enclosure to be conductive.
Available in 51 different selectable sizes.
Custom size is available.
↓Go MBF series page for the custom size order, width/length(depth) in 40～500mm and height in 20～250mm by 1mm intervals.
The inner surface is unfinished, allowing the enclosure to be conductive.
Available in 51 different selectable sizes.
Custom size is available.
↓Go MBF series page for the custom size order, width/length(depth) in 40～500mm and height in 20～250mm by 1mm intervals.
PRODUCT NO. / DIMENSIONS
| Product No. | External dimensions | Internal dimensions | Weight (g) | DXF | DWG | STP | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| W | H | D | w | h | d | ||||||
| MB4-3-5 | 35 | 25 | 45 | 30.2 | 23 | 42.4 | 23 | DXF | DWG | ||
| MB4-3-6 | 40 | 30 | 55 | 35.2 | 28 | 52.4 | 32 | DXF | DWG | ||
| MB5-4-7 | 50 | 40 | 70 | 45.2 | 38 | 67.4 | 51 | DXF | DWG | ||
| MB5-5-16 | 50 | 45 | 160 | 45.2 | 43 | 157.4 | 103 | DXF | DWG | ||
| MB6-4-25 | 55 | 40 | 250 | 50.2 | 38 | 247.4 | 153 | DXF | DWG | ||
| MB6-5-9 | 60 | 45 | 85 | 55.2 | 43 | 82.4 | 69 | DXF | DWG | ||
| MB6-5-12 | 60 | 50 | 120 | 55.2 | 48 | 117.4 | 97 | DXF | DWG | ||
| MB7-5-10 | 70 | 50 | 100 | 65.2 | 48 | 97.4 | 92 | DXF | DWG | ||
| MB7-7-7 | 70 | 70 | 70 | 65.2 | 68 | 67.4 | 87 | DXF | DWG | ||
| MB8-3-11 | 80 | 25 | 110 | 75.2 | 23 | 107.4 | 89 | DXF | DWG | ||
| MB8-6-8 | 80 | 55 | 80 | 75.2 | 53 | 77.4 | 91 | DXF | DWG | ||
| MB8-6-15 | 80 | 55 | 150 | 75.2 | 53 | 147.4 | 144 | DXF | DWG | ||
| MB8-6-33 | 75 | 55 | 325 | 70.2 | 53 | 322.4 | 270 | DXF | DWG | ||
| MB8-7-9 | 80 | 70 | 90 | 75.2 | 68 | 87.4 | 111 | DXF | DWG | ||
| MB8-7-18 | 80 | 70 | 180 | 75.2 | 68 | 177.4 | 190 | DXF | DWG | ||
| MB9-3-9 | 90 | 25 | 90 | 85.2 | 23 | 87.4 | 72 | DXF | DWG | ||
| MB9-6-13 | 90 | 60 | 125 | 85.2 | 58 | 122.4 | 142 | DXF | DWG | ||
| MB10-5-7 | 100 | 50 | 70 | 95.2 | 48 | 67.4 | 91 | DXF | DWG | ||
| MB10-7-20 | 100 | 65 | 200 | 95.2 | 63 | 197.4 | 228 | DXF | DWG | ||
| MB10-9-12 | 100 | 90 | 120 | 95.2 | 87 | 117.4 | 189 | DXF | DWG | ||
| MB10-10-10 | 100 | 100 | 100 | 95.2 | 97 | 97.4 | 176 | DXF | DWG | ||
| MB11-3-14 | 110 | 30 | 140 | 105.2 | 28 | 137.4 | 129 | DXF | DWG | ||
| MB11-7-11 | 110 | 70 | 110 | 105.2 | 68 | 107.4 | 159.5 | DXF | DWG | ||
| MB11-7-15 | 110 | 65 | 150 | 105.2 | 63 | 147.4 | 192 | DXF | DWG | ||
| MB11-8-25 | 110 | 75 | 250 | 105.2 | 72 | 247.4 | 317 | DXF | DWG | ||
| MB12-3-12 | 120 | 25 | 120 | 115.2 | 23 | 117.4 | 115 | DXF | DWG | ||
| MB12-5-18 | 120 | 50 | 175 | 115.2 | 47 | 172.4 | 200 | DXF | DWG | ||
| MB12-8-18 | 120 | 75 | 175 | 115.2 | 72 | 172.4 | 252 | DXF | DWG | ||
| MB12-10-16 | 120 | 100 | 160 | 115.2 | 97 | 157.4 | 277 | DXF | DWG | ||
| MB13-3-18 | 130 | 30 | 180 | 125.2 | 28 | 177.4 | 183 | DXF | DWG | ||
| MB13-6-9 | 130 | 60 | 90 | 125.2 | 58 | 87.4 | 143.5 | DXF | DWG | ||
| MB14-5-20 | 140 | 50 | 200 | 135.2 | 47 | 197.4 | 250 | DXF | DWG | ||
| MB14-6-14 | 140 | 60 | 140 | 135.2 | 57 | 137.4 | 214 | DXF | DWG | ||
| MB14-8-20 | 140 | 75 | 200 | 135.2 | 72 | 197.4 | 312 | DXF | DWG | ||
| MB15-3-15 | 150 | 30 | 150 | 145.2 | 28 | 147.4 | 176 | DXF | DWG | ||
| MB15-3-21 | 150 | 30 | 210 | 145.2 | 28 | 207.4 | 236 | DXF | DWG | ||
| MB15-7-10 | 150 | 70 | 100 | 145.2 | 68 | 97.4 | 186 | DXF | DWG | ||
| MB15-12-20 | 150 | 120 | 200 | 144.4 | 116.4 | 197 | 494 | DXF | DWG | ||
| MB16-6-25 | 160 | 60 | 250 | 155.2 | 57 | 247.4 | 358 | DXF | DWG | ||
| MB16-9-25 | 160 | 85 | 250 | 155.2 | 82 | 247.4 | 431 | DXF | DWG | ||
| MB18-8-13 | 180 | 75 | 130 | 175.2 | 72 | 127.4 | 272 | DXF | DWG | ||
| MB18-14-23 | 180 | 140 | 230 | 174.4 | 136.4 | 227 | 665 | DXF | DWG | ||
| MB19-9-30 | 190 | 85 | 300 | 184.4 | 81.4 | 297 | 678 | DXF | DWG | ||
| MB20-8-15 | 200 | 80 | 150 | 194.4 | 76.4 | 147 | 400 | DXF | DWG | ||
| MB20-8-20 | 200 | 80 | 200 | 194.4 | 76.4 | 197 | 492 | DXF | DWG | ||
| MB21-9-35 | 210 | 90 | 350 | 204.4 | 86.4 | 347 | 843 | DXF | DWG | ||
| MB21-16-26 | 210 | 160 | 260 | 203.2 | 155.5 | 256.4 | 1091 | DXF | DWG | ||
| MB23-10-40 | 230 | 100 | 400 | 224.4 | 96.4 | 397 | 1051 | DXF | DWG | ||
| MB24-18-29 | 240 | 180 | 290 | 233.2 | 175.5 | 286.4 | 1381 | DXF | DWG | ||
| MB25-10-18 | 250 | 100 | 175 | 244.4 | 96.4 | 172 | 588.5 | DXF | DWG | ||
| MB30-12-20 | 300 | 120 | 200 | 294.4 | 116.4 | 197 | 815 | DXF | DWG | ||
